Drawing Description **** New Listing |
Pic |
Drawing File No. |
| 1/2 Ton Converto Trailer
Landing Leg |
|
Converto leg.pdf |
| 1/2 Ton Converto Trailer,
Lunette Socket**** |
|
converto.pdf |
| MBT & T3 Safety Chain Measurements
(Each link with dimensions) |
 |
MBT-chain.pdf
|
| Willys MBT, Trailer, Spring
Plate, Lower, with lower Shock Absorber attaching shaft.( Not suitable for
Bantam Trailers as these were attached with Nuts) |
|
MBT-sprp.pdf |
| Willys MBT, Bantam Trailer
Lunette **** |
|
lunette.pdf |
| Willys MBT & Bantam
T3 Handbrake Pivot Bolt & Castle Nut |
|
MBT-HB-pivot bolt.pdf |
| Willys MBT, Bantam Trailer Data
Plate hole Location**** |
|
MBT-Bantam-Data.pdf |
| Bolts & Castle Nuts - Through A-Frame to Casting and Landing Leg for attachment (New May 2016) |
|
MBT-Bolts-A-Frame |
| Willys MBT, Bantam Trailer
Handbrake Assembly. BELL CRANK |
|
MBT-HB1.pdf |
| Willys MBT, Bantam Trailer
Handbrake Assembly. FULCRUM (Ratchet Bracket) |
|
MBT-HB2.pdf |
| Willys MBT, Bantam Trailer
Handbrake Assembly. PAWL |
|
MBT-HB3.pdf |
| Willys MBT, Bantam Trailer
Handbrake Assembly. HAND BRAKE BODY (Handle) |
|
MBT-HB4.pdf |
| Willys MBT, Bantam Trailer
Handbrake Assembly. LEVER PAWL ROD (Inside handle) [This and above 4
drawings are to modify '30 Ford Model A handles to Bantam/MBT
specifications] |
|
MBT-HB5.pdf |
| |
|
|
| Willys MBT, Bantam Trailer
Handbrake Assembly. CABLE HOOK BOLT (From Bell Crank to cable
equalizer) |
|
MBT-HB6.pdf |
| Willys MBT, Bantam Trailer
Handbrake Assembly. CABLE EQUALIZER |
|
MBT-HB7.pdf |
| Willys MBT, Bantam Trailer
Handbrake Assembly. LEVER ROD (From Handle to Bell Crank) |
|
MBT-HB8.pdf |
| Willys MBT, Bantam Trailer FRONT
SPRING FRAME BRACKET Incl. Side Support Bracket (Pics on JeepDraw Home
Page) |
|
MBT-fssb.pdf |
| Willys MBT, Bantam Trailer
A-Frame Braces and Reinforcing Inserts (Pics on JeepDraw Home
Page) |
|
MBT-A-FM.pdf |
| Willys MBT, Bantam Trailer Light
Bracket, Tom Campbell Drawing |
|
MBT-Lg-L.pdf |
| Willys MBT, Bantam Trailer, Rear
Cross Member for Fabrication, complete with Hole Locations |
|
MBT-RX.pdf |
| Willys MBT, Bantam Trailer Mid
Cross Members for Fabrication, complete with Hole Locations (Pics on
JeepDraw Home Page) |
|
MBT-XMem.pdf |
| Willys MBT, Bantam Trailer,
Cross Member Gusset Plates - Side Frame to cross Member (Pics on JeepDraw
Home Page) |
|
mbt-gust.pdf |
| Willys MBT, Bantam Trailer,
Support Leg (Fabrication Pics on JeepDraw Home Page) |
|
MBT-LG.pdf |
| Willys MBT, Bantam Trailer,
Support Leg Pivot Casting Fabrication ( 3 Drawing set) Fabrication Pics on
JeepDraw Home Page. |
|
MBT-SP-1,2,3.pdf |
| Willys MBT, Bantam
and M100 Trailer, Handle, Support, Stand,( For locking the support leg to the swivel plate) Fabrication pics on JeepDraw Home Page |
|
mt-plunr.pdf |
| Willys MBT, Bantam Wiring
Diagram in Colour |
|
MBT-wire.pdf |
| Willys MBT Spring Leaf Clips
Long and short (Fabrication pics on JeepDraw Home Page) |
|
mbt-spr.pdf |
| Willys MBT, Bantam Trailer,
Brake Drum Hub Cover Plate |
|
MBT-HUB.pdf |
| |
|
|
| Willys MBT, Tandem Trailer -
Trailer Socket Box and Frame Braces, correct special washers (3 Drawing Set)**** |
|
MBT-Cdnp, Cdn2,Cdn3 |
| Willys MBT, Bantam Trailer, Side Reflector
Hole Positions 1 Drawing for Left & Right sides. |
|
MBT-S-R.pdf
|
| Willys MBT, Bantam Trailer, Tub
- Rear Panel Fabrication and Reflector Hole Locations |
|
mbt-rpan.pdf |
| Willys MBT, Bantam Trailer, Tub
- Front Panel Fabrication and Hooks Location Needed if you have an MD Juan Repro Tub to place
hooks in the correct position |
|
mbt-fpan.pdf |
| Willys MBT, Bantam Trailer - Fender
Brackets and Location |
|
MBT-FEN1.pdf
|
| Willys MBT & Bantam Front Cross Member (Angle Iron
type)with Hole and rivet locations Needed if you have an MD Juan
frame. |
|
MBT-F-XM.pdf
|
| Willys MBT & Bantam Frame Side Members |
|
MBT-SIDE-F.pdf
|
| Willys MBT & Bantam Light Switch Bracket ( Front of frame) |
|
MBT-F-SP.pdf
|
| Willys MBT & Bantam Pass. Side Front Reinforcing bracket |
|
MBT-F-LS.pdf
|
| Willys MBT Shock Absorber
Bracket on the frame |
|
MBT-sh_b.pdf
|
| Willys MBT & Bantam A-Brace retaining Brackets (Soon) |
|
|
| Cover, Canvas, MBT & Bantam
( Not suitable for Post War, as these are 4" wider) |
|
Canvas-Trailer.pdf |
| MBT - Bantam Side Panel Hook Locations
|
|
MBT-Shks.pdf
|
| M100 Trailer Intervehicular Storage Box ( 4
drawings & 1 Manual Drawing set) Now Includes Mounting
Brackets |
|
M100-1,2,3,4,5.pdf |
